Ford Rotunda VCM I (VCM 1) Diagnostic Interface Metal Threaded Locking USB PC Data Cable
Replace worn or intermittent cables on your Orijinal Ford / Mazda / JLR / Honda VCM I (Vehicle Communication Module 1) with a shielded, full-pin industrial harness built for reliable workshop diagnostics.
- Rotunda 164-R9801 / H-06-USB
- Full-Pin Pure Copper
- Locking Connector
- 100% Continuity Tested
Engineered for Professional Workshop Demands
The Ford VCM 1 (VCM I) Metal Kilitli USB Data Kablosu is built to deliver speed, accuracy, and stability in busy service bays.
Authentic 1:1 OEM Full Pinout
Unlike budget cables with missing wires, every data, ignition sense, and power pin required for Yüksek Hızlı İzoleli USB 2.0 VCM I Ana Ünite İletişimi is fully populated.
EMI/RFI Shielded Pure Copper Conductors
Multi-strand oxygen-free copper with foil shielding blocks electromagnetic interference during high-speed CAN and USB communication.
Locking Connectors with Strain Relief
Moulded strain-relief collars on both the Yuvarlak Metal Vidalı/Kilitli Endüstriyel VCM I Host Port Konnektörü and Standart USB 2.0 Tip-A PC Konnektörü (Çift Ferrit Filtreli) ends prevent internal wire fatigue.
Safe ECU Flashing & Calibration
Maintains rock-solid voltage and signal integrity during programming sessions in Ford IDS · Mazda IDS · JLR SDD.
UNINTERRUPTED DIAGNOSTIC LINK
Essential Replacement Harness for Orijinal Ford / Mazda / JLR / Honda VCM I (Vehicle Communication Module 1)
Over 80% of 'VCI Not Found' or 'Communication Error' faults are caused by damaged cables. Upgrading to this OEM-spec harness delivers:
- Instant, stable connection to all ECUs across Ford VCM I Kullanılan Tüm Ford, Mazda, Jaguar ve Land Rover Yetkili Servis Uygulamaları
- VCI-side termination: Yuvarlak Metal Vidalı/Kilitli Endüstriyel VCM I Host Port Konnektörü
- Vehicle / PC termination: Standart USB 2.0 Tip-A PC Konnektörü (Çift Ferrit Filtreli)
- Full protocol pass-through: Yüksek Hızlı İzoleli USB 2.0 VCM I Ana Ünite İletişimi
WORKSHOP DURABILITY
Oil, Heat & Crush Resistant Industrial Jacket
Built to survive daily plug-in cycles on the workshop floor:
- Gold/nickel-plated terminal pins resist oxidation and contact wear
- High-flexibility elastomer jacket remains supple in cold weather
- Reference part specification: Rotunda 164-R9801 / H-06-USB
- 100% pin-to-pin continuity tested prior to dispatch
ARCHITECTURE & SYSTEM COMPATIBILITY
Ford VCM 1 (VCM I) Metal Kilitli USB Data Kablosu Software, Protocol & ECU Coverage
Hardware and operating parameters engineered for uninterrupted dealer-level communication:
- Full Pinout: Matches Rotunda 164-R9801 / H-06-USB OEM wiring specification
- Locking Fit: Vibration-resistant connectors prevent dropouts
- Pure Copper: High-speed CAN/DoIP/USB transmission without packet loss
- Orijinal Ford / Mazda / JLR / Honda VCM I (Vehicle Communication Module 1)
Detailed Visual & Technical Showcase
Close-up details and application views of the Ford VCM 1 (VCM I) Metal Kilitli USB Data Kablosu.
Technical Specifications & System Parameters
Complete manufacturer-verified technical data and operating ranges.
| Product Model | Ford Rotunda VCM I (VCM 1) Diagnostic Interface Metal Threaded Locking USB PC Data Cable |
|---|---|
| Reference Part No | Rotunda 164-R9801 / H-06-USB |
| Compatible VCI Unit | Orijinal Ford / Mazda / JLR / Honda VCM I (Vehicle Communication Module 1) |
| Compatible Software | Ford IDS · Mazda IDS · JLR SDD |
| VCI Side Connector | Yuvarlak Metal Vidalı/Kilitli Endüstriyel VCM I Host Port Konnektörü |
| Vehicle / PC Connector | Standart USB 2.0 Tip-A PC Konnektörü (Çift Ferrit Filtreli) |
|---|---|
| Supported Protocols | Yüksek Hızlı İzoleli USB 2.0 VCM I Ana Ünite İletişimi |
| Vehicle / Equipment Range | Ford VCM I Kullanılan Tüm Ford, Mazda, Jaguar ve Land Rover Yetkili Servis Uygulamaları |
| Quality & Warranty | No Warranty on Consumable Cables (100% Tested Before Dispatch) |
Workshop Application & Operating Guide
Recommended 4-step standard procedure for accurate results.
Inspect Connector Pins
Verify both sockets are clean and free of bent pins or debris before connecting.
Lock VCI Connector
Seat the Yuvarlak Metal Vidalı/Kilitli Endüstriyel VCM I Host Port Konnektörü firmly onto your VCI unit and tighten any locking screws.
Attach Vehicle / PC Plug
Connect the Standart USB 2.0 Tip-A PC Konnektörü (Çift Ferrit Filtreli) and confirm the VCI power/status LEDs illuminate.
Disconnect by Connector Body
Always grasp the moulded connector body rather than pulling on the cable jacket.
Package Contents — Ready for the Workshop
Complete kit inspected prior to dispatch.
- 1 × Ford Rotunda VCM I (VCM 1) Diagnostic Interface Metal Threaded Locking USB PC Data Cable (Rotunda 164-R9801 / H-06-USB)
- 1 × Protective Anti-Static Bag (100% Continuity Tested)
100% Pin Continuity & Quality Control Assurance
Every Ford VCM 1 (VCM I) Metal Kilitli USB Data Kablosu harness is 100% continuity- and isolation-tested on the Otoeko test bench prior to dispatch (Consumable cables carry no warranty against physical wear or strain).
Frequently Asked Questions
Key technical questions from technicians and workshops about the Ford VCM 1 (VCM I) Metal Kilitli USB Data Kablosu.
Which diagnostic interface does this cable fit?
It is specifically engineered for Orijinal Ford / Mazda / JLR / Honda VCM I (Vehicle Communication Module 1).
Are all internal pins populated?
Yes, it features a complete 1:1 OEM pinout supporting Yüksek Hızlı İzoleli USB 2.0 VCM I Ana Ünite İletişimi.
Will this fix intermittent connection drops?
Yes, if your existing cable has internal wire fatigue or loose pins, replacing it restores stable VCI communication.
Is it safe for ECU programming?
Yes, the shielded pure copper conductors and locking connectors ensure uninterrupted data transfer.
Which vehicles are supported?
Supports Ford VCM I Kullanılan Tüm Ford, Mazda, Jaguar ve Land Rover Yetkili Servis Uygulamaları.
What is the warranty policy on cables?
Diagnostic cables are consumable workshop items and carry no warranty against physical wear, but every unit is 100% continuity-tested prior to shipping.
