Peugeot & Citroën Lexia 3 Diagnostic Interface 16-Pin OBD-II V1 Main Cable (DB15 Plug)
Replace worn or intermittent cables on your Peugeot & Citroën Lexia 3 / XS Evolution (DB15 Girişli V1 veya Ara Kablolu) with a shielded, full-pin industrial harness built for reliable workshop diagnostics.
- PSA-9780-Z5-V1
- Full-Pin Pure Copper
- Locking Connector
- 100% Continuity Tested
Engineered for Professional Workshop Demands
The Lexia 3 OBD2 V1 Ana Kablosu (DB15 Vidalı Soket) is built to deliver speed, accuracy, and stability in busy service bays.
Authentic 1:1 OEM Full Pinout
Unlike budget cables with missing wires, every data, ignition sense, and power pin required for PSA High-Speed CAN · Body CAN · VAN-Bus · K-Line is fully populated.
EMI/RFI Shielded Pure Copper Conductors
Multi-strand oxygen-free copper with foil shielding blocks electromagnetic interference during high-speed CAN and USB communication.
Locking Connectors with Strain Relief
Moulded strain-relief collars on both the 15-Pin (DB15) Metal Vidalı Kilitli Konnektör and 16-Pin J1962 OBD-II Erkek Soket (PSA Multiplexed Tam Pin) ends prevent internal wire fatigue.
Safe ECU Flashing & Calibration
Maintains rock-solid voltage and signal integrity during programming sessions in PSA Diagbox · Lexia · PP2000.
UNINTERRUPTED DIAGNOSTIC LINK
Essential Replacement Harness for Peugeot & Citroën Lexia 3 / XS Evolution (DB15 Girişli V1 veya Ara Kablolu)
Over 80% of 'VCI Not Found' or 'Communication Error' faults are caused by damaged cables. Upgrading to this OEM-spec harness delivers:
- Instant, stable connection to all ECUs across Peugeot ve Citroën Tüm 16-Pin OBD-II Soketli Binek ve Ticari Araçlar
- VCI-side termination: 15-Pin (DB15) Metal Vidalı Kilitli Konnektör
- Vehicle / PC termination: 16-Pin J1962 OBD-II Erkek Soket (PSA Multiplexed Tam Pin)
- Full protocol pass-through: PSA High-Speed CAN · Body CAN · VAN-Bus · K-Line
WORKSHOP DURABILITY
Oil, Heat & Crush Resistant Industrial Jacket
Built to survive daily plug-in cycles on the workshop floor:
- Gold/nickel-plated terminal pins resist oxidation and contact wear
- High-flexibility elastomer jacket remains supple in cold weather
- Reference part specification: PSA-9780-Z5-V1
- 100% pin-to-pin continuity tested prior to dispatch
ARCHITECTURE & SYSTEM COMPATIBILITY
Lexia 3 OBD2 V1 Ana Kablosu (DB15 Vidalı Soket) Software, Protocol & ECU Coverage
Hardware and operating parameters engineered for uninterrupted dealer-level communication:
- Full Pinout: Matches PSA-9780-Z5-V1 OEM wiring specification
- Locking Fit: Vibration-resistant connectors prevent dropouts
- Pure Copper: High-speed CAN/DoIP/USB transmission without packet loss
- Peugeot & Citroën Lexia 3 / XS Evolution (DB15 Girişli V1 veya Ara Kablolu)
Detailed Visual & Technical Showcase
Close-up details and application views of the Lexia 3 OBD2 V1 Ana Kablosu (DB15 Vidalı Soket).
Technical Specifications & System Parameters
Complete manufacturer-verified technical data and operating ranges.
| Product Model | Peugeot & Citroën Lexia 3 Diagnostic Interface 16-Pin OBD-II V1 Main Cable (DB15 Plug) |
|---|---|
| Reference Part No | PSA-9780-Z5-V1 |
| Compatible VCI Unit | Peugeot & Citroën Lexia 3 / XS Evolution (DB15 Girişli V1 veya Ara Kablolu) |
| Compatible Software | PSA Diagbox · Lexia · PP2000 |
| VCI Side Connector | 15-Pin (DB15) Metal Vidalı Kilitli Konnektör |
| Vehicle / PC Connector | 16-Pin J1962 OBD-II Erkek Soket (PSA Multiplexed Tam Pin) |
|---|---|
| Supported Protocols | PSA High-Speed CAN · Body CAN · VAN-Bus · K-Line |
| Vehicle / Equipment Range | Peugeot ve Citroën Tüm 16-Pin OBD-II Soketli Binek ve Ticari Araçlar |
| Quality & Warranty | No Warranty on Consumable Cables (100% Tested Before Dispatch) |
Workshop Application & Operating Guide
Recommended 4-step standard procedure for accurate results.
Inspect Connector Pins
Verify both sockets are clean and free of bent pins or debris before connecting.
Lock VCI Connector
Seat the 15-Pin (DB15) Metal Vidalı Kilitli Konnektör firmly onto your VCI unit and tighten any locking screws.
Attach Vehicle / PC Plug
Connect the 16-Pin J1962 OBD-II Erkek Soket (PSA Multiplexed Tam Pin) and confirm the VCI power/status LEDs illuminate.
Disconnect by Connector Body
Always grasp the moulded connector body rather than pulling on the cable jacket.
Package Contents — Ready for the Workshop
Complete kit inspected prior to dispatch.
- 1 × Peugeot & Citroën Lexia 3 Diagnostic Interface 16-Pin OBD-II V1 Main Cable (DB15 Plug) (PSA-9780-Z5-V1)
- 1 × Protective Anti-Static Bag (100% Continuity Tested)
100% Pin Continuity & Quality Control Assurance
Every Lexia 3 OBD2 V1 Ana Kablosu (DB15 Vidalı Soket) harness is 100% continuity- and isolation-tested on the Otoeko test bench prior to dispatch (Consumable cables carry no warranty against physical wear or strain).
Frequently Asked Questions
Key technical questions from technicians and workshops about the Lexia 3 OBD2 V1 Ana Kablosu (DB15 Vidalı Soket).
Which diagnostic interface does this cable fit?
It is specifically engineered for Peugeot & Citroën Lexia 3 / XS Evolution (DB15 Girişli V1 veya Ara Kablolu).
Are all internal pins populated?
Yes, it features a complete 1:1 OEM pinout supporting PSA High-Speed CAN · Body CAN · VAN-Bus · K-Line.
Will this fix intermittent connection drops?
Yes, if your existing cable has internal wire fatigue or loose pins, replacing it restores stable VCI communication.
Is it safe for ECU programming?
Yes, the shielded pure copper conductors and locking connectors ensure uninterrupted data transfer.
Which vehicles are supported?
Supports Peugeot ve Citroën Tüm 16-Pin OBD-II Soketli Binek ve Ticari Araçlar.
What is the warranty policy on cables?
Diagnostic cables are consumable workshop items and carry no warranty against physical wear, but every unit is 100% continuity-tested prior to shipping.
